FAN STATOR CASE - APPROVED/REPAIRS
1. General
A. This procedure gives instructions on how to remove and install the 1st-stage stator vanes, the
fairings, and the inner shroud.
TASK 72-33-01-008-001-G00
2. Remove the 1st-Stage Stator Vane Assembly
A. References
Reference Title
72-31-01 P/B 401 FAN ROTOR SPINNER - REMOVAL/INSTALLATION
72-31-02 P/B 401 FAN ROTOR BLADES - REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-6797 Heater - Case, Aft Fan
767-200
Part #: 2C6372G03 Supplier: 06083
Part #: 2C6372G04 Supplier: 06083
STD-7049
Marker
C. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
D. Remove the 1st-Stage Stator Vane Assembly
SUBTASK 72-33-01-018-002-G00
CAUTION
MAKE SURE THAT OBJECTS DO NOT FALL THROUGH THE OPEN VALVES
INTO THE ENGINE. DAMAGE TO THE ENGINE CAN OCCUR.
CAUTION
YOU MUST PUT AN IDENTIFICATION MARK ON ALL THE REMOVED PARTS.
DAMAGE TO THE ENGINE CAN OCCUR IF THE PARTS ARE NOT PUT BACK
IN THE CORRECT LOCATION.
(1) Remove the fan rotor spinner (PAGEBLOCK 72-31-01/401).
SUBTASK 72-33-01-018-003-G00
(2) Remove the necessary fan rotor blades to get access to the area where you will do work
(PAGEBLOCK 72-31-02/401).
SUBTASK 72-33-01-038-004-G00
(3) Remove the screws that hold the fan stator fairing to the 1st-stage stator case.
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-01
NoC
Page 801
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
