A
CASE
(HIDDEN)
FAIRING
CASE
CASE
VANES
INTERSTAGE
SEAL
SEE
A
2nd-STAGE
3rd-STAGE
2nd-STAGE
SHROUD
1st-STAGE
1st-STAGE
26031 S00061422930_V1
Fan Stator Assembly
Figure 601/72-33-01-990-801-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-01
NoC
Page 603
D633T1B7 Dec 22/2016
