Boeing 767 - Subject 72-61-02 - SEAL - ACCESSORY DRIVE OIL; Pageblock 72-61-02;401 - ACCESSORY DRIVE OIL SEAL - REMOVAL;INSTALLATION; Task 72-61-02-004-027-G00 - Remove the Oil Seal

ACCESSORY DRIVE OIL SEAL - REMOVAL/INSTALLATION
1. General
A. In this procedure the accessory drive oil seal will be referred to as the oil seal.
B. This procedure gives instructions on how to replace the oil seals that are between the accessory
gearbox and some components. The components are: the fuel pump, the main engine control, the
starter, the hydraulic pump, and the itegrated drive generator (IDG). The same procedure is used for
each oil seal.
TASK 72-61-02-004-027-G00
2. Remove the Oil Seal
A. References
Reference Title
24-11-01 P/B 401 Config 3 INTEGRATED DRIVE GENERATOR -
REMOVAL/INSTALLATION
29-11-03 P/B 401 CENTER HYDRAULIC SYSTEM AIR DRIVEN PUMP (ADP) -
REMOVAL/INSTALLATION
29-11-03 P/B 401 Config 3 CENTER HYDRAULIC SYSTEM AIR DRIVEN PUMP (ADP) -
REMOVAL/INSTALLATION
71-11-04 P/B 201 FAN COWL PANELS - MAINTENANCE PRACTICES
(OPEN/CLOSE)
71-11-06 P/B 201 CORE COWL PANELS - MAINTENANCE PRACTICES
(OPENING/CLOSING)
73-11-01 P/B 401 FUEL PUMP - REMOVAL/INSTALLATION
73-21-01 P/B 401 MAIN ENGINE CONTROL - REMOVAL/INSTALLATION
78-31-00 P/B 201 THRUST REVERSER SYSTEM - MAINTENANCE PRACTICES
80-11-01 P/B 401 STARTER - REMOVAL/INSTALLATION
B. Tools/Equipment
NOTE: When more than one tool part number is listed under the same "Reference" number, the
tools shown are alternates to each other within the same airplane series. Tool part numbers
that are replaced or non-procurable are preceded by "Opt:", which stands for Optional.
Reference Description
SPL-5655 Tool - Fixture, Accessory Gear Box (AGB) Mating Ring Removal
767-200
Part #: 2C14138G01 Supplier: 06083
SPL-5656 Fixture - Removal, Accessory Gear Box (AGB) Mating Rings
767-200
Part #: 2C14138G02 Supplier: 06083
STD-6422
Jackscrews - 1/4x28 UNF
C. Location Zones
Zone Area
410 Left Powerplant
415 Left Powerplant Fan Reverser - Left
420 Right Powerplant
425 Right Powerplant Fan Reverser - Left
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-61-02
NoC
Page 401
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
