FWD
SEE
A
A
1183896-00-A
[9] OIL
SUPPLY
LINE
[3]
BRACKET
[4] NUT
[6]
BOLT
[8]
CLAMP
[4] NUT
[7] NUT
[14]
PACKING
[2]
FLAME
ARRESTER
[1]
INSULATION
BLANKET
[13]
CARBON
SEAL
HOUSING
TURBINE
REAR
FRAME
[10]
CENTER
VENT
TUBE
[11]
OIL
SLINGER
[12]
NUT
DUCT
[16]
PACKING
[15]
PACKING
SPANNER
NUT
L80531 S00061423182_V1
C-Sump Vent Installation
Figure 403/72-53-02-990-804-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-53-02
NoC
Page 407
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999 POST SB CF6-80A-72-A675
