FWD
SEE
A
A
[3]
BRACKET
[17]
NUT
[2]
FLAME
ARRESTER
[6]
BOLT
[4] NUT
[8]
CLAMP
[9] OIL
SUPPLY
LINE
[4] NUT
[7] NUT
[5]
THERMAL
SHIELD
[10]
INSULATION
BLANKET
[11]
CARBON
SEAL
HOUSING
[12]
PACKING
TURBINE
REAR
FRAME
[14]
OIL
SLINGER
1]
RETAINER
RING
[15]
CENTER
VENT
TUBE
NUT
SPANNER
[16]
PACKING
[18]
PACKING
1184087-00-A
L80465 S00061423179_V1
C-Sump Vent Installation
Figure 401/72-53-02-990-801-G00 (Sheet 1 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-53-02
NoC
Page 404
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999 PRE SB CF6-80A-72-0084
