B
C
D
[9]
WASHER/
BUSHING
IGV 1st AND
2nd-STAGES
[13]
SHROUD
[12]
FLANGED
BUSHING
[7]
SPACER
[1]
LOCKNUT
[3]
LEVER
ARM
[2]
SLEEVE
[4]
LEVER
ARM
PIN
SLEEVE
[11]
ACTUATION
RING
[10] VANE
[8]
BUSHING/WASHER
(FLANGED)
[5]
LEVER
ARM
PIN
WASHER
[7]
SPACER
[2]
SLEEVE
[1]
LOCKNUT
[3]
LEVER
ARM
[5]
LEVER
ARM
PIN
WASHER
[4]
LEVER
ARM
PIN
SLEEVE
[8]
BUSHING/WASHER
(FLANGED)
[10] VANE
3rd AND
4th-STAGES
[1]
LOCKNUT
[7]
SPACER
[6] JAM NUT
[3]
LEVER
ARM
[2]
SLEEVE
[11]
ACTUATION
RING
[10] VANE
[9]
WASHER/BUSHING
[8]
BUSHING/WASHER
(FLANGED)
[5]
LEVER
ARM
PIN
WASHER
[4]
LEVER
ARM
PIN
SLEEVE
5th-STAGE
[11]
ACTUATION
RING
[9]
WASHER/BUSHING
26114 S00061423051_V1
Front Stator Assembly of the High Pressure Compressor
Figure 801/72-35-00-990-809-G00 (Sheet 2 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 804
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
