SEE
A
A
HOLE
FWD
CENTER
VENT TUBE
SHAFT
FAN MID
VESPEL
INSERT
(4
LOCATIONS)
(4
LOCATIONS)
WRENCH
SLOT
AREA
G
AREA
J
0.75 INCH
DIA
MAX.
(19.0
mm)
OF
RESIN
OVERLAP
THE
RESIN
BY
0.01-0.07
INCH
(0.3-1.8
mm)
(4
LOCATIONS)
RESIN
WITH
EPOXY
FILL
THE
HOLE
THREADS
TUBE
CENTER
VENT
24977 S00061422845_V1
Center Vent Tube Installation
Figure 204/72-31-00-990-804-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-00
NoC
Page 210
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
