A
A
SEE
FAN BLADE
RTV-108 OR RTV-103
1ST-STAGE DISK
1ST-STAGE DISK
SPACER
FAN BLADE
RETAINER
SPACER
RETAINER
C14198 S00061422922_V1
RTV Sealant on the Fan Rotor Assembly
Figure 806/72-31-02-990-811-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-31-02
NoC
Page 817
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
