SEE
A
ACOUSTICAL
LINER
SEE
OUTER
OUTLET
GUIDE
VANES
B
AFT FAN
STATOR CASE
A
B
(25 MM)
(25 MM)
AREA A
AREA B
FAN FRAME STRUT
1.0 IN.
1.0 IN.
3.0 IN. (76 MM)
25725 S00061422968_V1
Fan Frame Strut and Case Inspection
Figure 603/72-33-04-990-809-G00 (Sheet 1 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-04
NoC
Page 610
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
