4 PLACES
8.5
(215.9 MM)
TYPICAL
43.1 R
(1094.7 MM)
(7.06-7.29 MM)
DIA
THRU 5 HOLES
EQUALLY SPACED
0.7
(17.8 MM)
1.69 (42.93 MM)
0.278-0.287
NOTE: ALL DIMENSIONS GIVEN
IN INCHES WITH METRIC
UNITS IN PARENTHESES
MATERIAL: 6061T6 ALUMINUM 0.190
(4.83
MM) THICK
0.1 R (2.54 MM)
25002 S00061422979_V1
Doubler for Cracked Casing Rib
Figure 803/72-33-04-990-805-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-04
NoC
Page 813
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
