A
OUTER LINER
FORWARD
FAN
FRAME/CASE
ASSEMBLY
SEE
A
LINER
SECTION
SECTION
93916 S00061422994_V1
Acoustial Liner Sections for the Fan Frame and Case
Figure 402/72-33-05-990-802-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-33-05
NoC
Page 404
D633T1B7 Dec 22/2016
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
