BORESCOPE
LIGHT GUIDE CABLE
POWER SUPPLY
MOTOR ASSEMBLY
ARTICULATING (0-90 DEGREES + 10 DEGREES)
BLADE BORESCOPE BLENDING TOOL
ARTICULATING (0-90 DEGREES + 10 DEGREES)
GRIND/BLENDING HEAD
AND WORKING CHANNEL
BORESCOPE HOUSING
DRIVE MOTOR
1132825-00-A
F56899 S00061423095_V1
HPC Blade Borescope Blending Tool
Figure 812/72-35-00-990-820-G00 (Sheet 1 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-35-00
NoC
Page 852
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
