SEE
A
FWD
A
NO.
6
BEARING
AIR/OIL
SEAL
FORWARD
FLANGE
SERVICE
TUBE
PAD
SCAVENGE
TUBE
SERVICE
TUBE
PAD
OIL
SUPPLY
TUBE
STRUT
(12
LOCATIONS)
NO.
6
BEARING
SUPPORT
AFT
FLANGE
GROUND
HANDLING
BOSS
(3
O'CLOCK
AND
9
O'CLOCK)
24970 S00061423174_V1
Turbine Rear Frame Inspection
Figure 601/72-53-01-990-801-G00
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-53-01
NoC
Page 604
D633T1B7 Dec 22/2016
