A
A
SEE
A
TRAILING
EDGE
UNSERVICEABLE
WEAR
LEADING
EDGE
(WITH
SPRAYED-ON
HARDCOAT)
MIDSPAN
SHROUD
TIPS
PORT
B1-1:
TOP
OF
MID
SPAN
SHROUDS
WITH
SPRAYED-0N
HARDCOAT
BORESCOPE
VIEW FROM
NO
WEAR
25341 S00061422706_V1
Mid-Span Shroud of the Compressor 1st-Stage Blade with Sprayed-on Hardcoat
Figure 603/72-00-00-990-806-G00 (Sheet 1 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 626
D633T1B7 Aug 22/2017
