SEE
B
B
B
MIDSPAN SHROUDS
MIDSPAN SHROUD TIPS
UNSERVICEABLE WEAR
TRAILING EDGE
SPRAYED-ON HARDCOAT
WITH CARBOLOY
WEAR PADS
(WITH CARBOLOY WEAR PADS)
BORESCOPE VIEW FROM
B1-1: UP AND UNDER THE
____ NOTE: A CARBOLOY PAD
THAT TOUCHES A
IS PERMITTED
NO WEAR
WEAR AREA (CARBOLOY
CLEARANCE
AND JAGGED
PAD IS GONE)
LEADING EDGE
159596 S00061422710_V1
Mid-Span Shroud of the Compressor 1st-Stage Blade with Carboloy Pad
Figure 605/72-00-00-990-809-G00 (Sheet 2 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 630
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
