C
ON TOP OF MIDSPAN
SHROUD FROM PORT B1-1
BORESCOPE VIEW LOOKING DOWN
C
SEE
MIDSPAN SHROUD SURFACES
THE MIDSPAN
TIP DAMAGE
SCRATCHES OR GOUGES
ON THE UPPER/LOWER
DENTS ON THE
AIRFOIL OR
AIRFOIL FILLET
ABOVE OR BELOW
SHROUDS
TRAILING EDGE
FILLET
C81029 S00061422712_V1
Midspan Shroud Inspection of the 1st-Stage Blades
Figure 606/72-00-00-990-811-G00 (Sheet 2 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 632
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
