BORESCOPE
BOSS
PIN
AREA C
RADIAL
AXIAL
LEADING
EDGE
TRAILING
EDGE
SEE
CF8-3788-03A
C-C
C
A-A
C
1
ADAPTER
TACK WELD
1
(6 LOCATIONS)
SLEEVE CAP
BORESCOPE BOSS
(ON ONE NOZZLE
AIRFOIL CAVITY
SLEEVE COLLARS
TACK WELD
1
B-B
(6 LOCATIONS)
SEGMENT, EACH SET)
THE SLEEVES ARE TACK WELDED OR BRAZED.
(6.35 mm)
0.250 INCH
(5.08 mm)
0.200 INCH
26429 S00061422725_V1
2nd-Stage High Pressure Turbine Nozzle Inspection
Figure 615/72-00-00-990-824-G00 (Sheet 2 of 2)
767
AIRCRAFT MAINTENANCE MANUAL
CF6-80A SERIES ENGINES
72-00-00
NoC
Page 645
D633T1B7 Aug 22/2017
ECCN 9E991 BOEING PROPRIETARY - Copyright © Unpublished Work - See title page for details
EFFECTIVITY
ABX 001-007, 011, 012, 016-019, 021, 022, 025, 101,
109, 114, 115, 314-999
