HEIDENHAIN MANUALPLUS 620 Technical Manual

1454 HEIDENHAIN Technical Manual MANUALplus 620
Dashboard display
of the gantry axis
 To be able to display the position of the gantry axis in the dashboard, copy
the dashboard element DB_X1_POS located in CfgDashboardElemnt and
rename it to DB_G1_POS.
 Then enter the dashboard element (DB_G1_POS) into the elementList of a
dashboard display (e.g. DB_DEFAULT).
Activating the
gantry axis
 Switch off the test mode of the gantry axis G1 by entering MP_testMode
=FALSE. Please remember that the gantry axis must be connected
electrically if MP_axisMode = Active. In this case, you should also verify if
a speed encoder input is assigned to the gantry axis in
MP_speedEncoderInput, and a nominal speed command output in
MP_pwmSignalOutput.
 Before exiting the configuration editor, save all the changes you have made
and restart the control.
Settings in the configuration editor MP number
DisplaySettings
CfgDashboardElemnt
DB_G1_POS
dashboardpicType: ActualValue
attribut: 1
entityList: G1
113100
113101
113102
113103
Settings in the configuration editor MP number
DisplaySettings
CfgDashboard
DB_DEFAULT
elementList
113200
113201
Settings in the configuration editor MP number
Axes
PhysicalAxis
[W1]
CfgAxis
testMode 300106
