 Specify the number of swivel positions in MP_maxSwivelPosition.
 Check the description, and add the dimensions of the tool carrier TH1_REV
(see "Tool carriers" on page 1396).
In the standard configuration, three tool holders are configured for each of the
12 swivel pockets, meaning a total of 36 tool holders for the tool turret. A key
name is assigned to each tool holder. The prepared key names include:
 the tool carrier (TH1)
 the number of the tool holder (TMx01 to TMx12)
 the number of the swivel pocket (TM0xx...TM2xx)
 the type of the tool carrier (MULTI or REV).
 Delete the key names of unused tool holders.
The standard configuration includes 36 tool holders on the tool turret
(TH1_TM001_REV .. TH1_TM212_REV).
Settings in the configuration editor MP number
Aggregates
ToolHolder
TH1_REV
CfgTHDescription
ordinalNr
. . .
maxSwivelPosition
600200
600203
. . .
600208
Settings in the configuration editor MP number
Aggregates
ToolHolder
TH1_REV
CfgToolMountKeys
toolMountKeys
[0]:TH1_TM001_REV
...
[36]:TH1_TM212_REV
600101
...
