338 HEIDENHAIN Technical Manual MANUALplus 620
Changing key
names
Press the CHANGE KEY NAME soft key to change the key name of an object, for
example, from Kinem1 to Kinem_XYZ.
Saving input values The input values are buffered with the OK soft key. The CANCEL soft key closes
the dialog box without buffering the value. All changes that have been made
but not yet saved are marked with a symbol on the left side of the screen.
Press the SAVE soft key to actually save the changes you have made.
Certain data cannot be stored while an NC program is running. The message
Cannot change parameter during program run appears. In this case the
program must first be stopped and exited. Then the data can be saved.
Some data take effect as soon as they have been saved.
Others require that the axes be referenced again, or that the system be
restarted. This is indicated in a corresponding message.
Change list A machine-parameter change list is displayed after pressing the SAVE or END
soft key. The Configuration data changed window gives you an overview of
all changed parameters. You can save, discard or cancel the changes:
The control also saves a list of the last 20 changes to the configuration data.
In this list you can see all changes performed, and can undo any of them. The
change list is maintained upon power-off of the control. The change list is
reached in the configuration editor via the MORE FUNCTIONS and
DISCARD CHANGES soft keys.
Settings in the configuration editor MP number
System
CfgConfigSettings
undoListSize
dispParamNumbers
106501
106503
