Command table (Continued) D
Remote jack (CI-V) information
Cmd. Sub cmd. Data Description
1A 05 0162 00 to 15 Send/read NR level for the DR
mode
(00=0 to 15=15)
0163 0000 to
0255
Send/read the VOX gain
(0000=0% to 0255=100%)
0164 0000 to
0255
Send/read the ANTI-VOX gain
(0000=0% to 0255=100%)
0165 00 to 20 Send/read the VOX delay time
(00=0.0 sec. to 20=2.0 sec.)
0166 0020 to
0130
Send/read the BK-IN delay time
(0020=2.0d to 0130=13.0d)
0167 00/01 Send/read the recording mode
(00=TX&RX, 01=RX Only)
0168 00/01 Send/read the squelch status for
the RX voice audio recording
(00=Always, 01=Squelch Auto)
0169 00/01 Send/read the QSO audio record
file Split function setting
(00=OFF, 01=ON)
0170 00/01 Send/read the PTT Automatic
Recording function setting
(00=OFF, 01=ON)
0171 00 to 03 Send/read the Skip Timer setting
while playing back
( 00=3 sec., 01=5 sec., 02=10 sec.,
03=30 sec.)
0172 00 to 02 Send/read the Standby Beep set-
ting
( 00=OFF, 01=ON, 02=ON (to
me:High Tone))
0173 00 to 02 Send/read Auto Reply setting
(00=OFF, 01=ON, 02=Voice)
0174 00/01 Send/read the DV Data TX setting
(00=PTT, 01=Auto)
0175 00 to 02 Send/read the Digital Monitor set-
ting
(00=Auto, 01=Digital, 02=Analog)
0176 00/01 Send/read the Digital Repeater set-
ting function setting
(00=OFF, 01=ON)
0177 00/01 Send/read the RX Call Sign Auto
Write setting
(00=OFF, 01=Auto)
0178 00/01 Send/read the RX RPT Call Sign
Auto Write setting
(00=OFF, 01=Auto)
0179 00/01 Send/read the DV Auto Detect
setting
(00=OFF, 01=ON)
0180 00/01 Send/read the RX Record (RPT)
setting
(00=ALL, 01=Latest Only)
0181 00/01 Send/read the BK function setting
(00=OFF, 01=ON)
0182 00/01 Send/read the EMR mode setting
(00=OFF, 01=ON)
0183 0000 to
0255
Send/read EMR AF Level
(0000=0% to 0255=100%)
0184 00 to 02 Send/read the external GPS re-
ceiver setting
( 00=OFF, 01=External GPS,
02=Manual)
0185 00/01 Send/read the GPS Receiver Baud
setting
(00=4800 bps, 01=9600 bps)
Cmd. Sub cmd. Data Description
1A 05 0186 see p. 20-13 Send/read the manually pro-
grammed position
0187 00/01 Send/read the GPS Indicator set-
ting
(00=OFF, 01=ON)
0188 00/01 Send/read the Position Format
setting
(00=ddd˚mm.mm’, 01=ddd˚mm’ss”)
0189 00/01 Send/read the Distance and
Altitude unit
(00=meter, 01=feet/mile)
0190 00 to 02 Send/read the GPS speed unit
(00=km/h, 01=mph, 02=knots)
0191 see p. 20-13 Send/read GPS alarm area (Group)
0192 00 to 02 Send/read GPS alarm area
(RX/Memory)
( 00=Limited, 01=Extended,
02=Both)
0193 00 to 02 Send/read the GPS TX Mode
setting
( 00=OFF, 01=GPS(DV-G),
02=GPS-A(DV-A))
0194 00/01 Send/read the GPS (RMC)
Sentence setting
(00=OFF, 01=ON)
0195 00/01 Send/read the GPS (GGA)
Sentence setting
(00=OFF, 01=ON)
0196 00/01 Send/read the GPS (GLL)
Sentence setting
(00=OFF, 01=ON)
0197 00/01 Send/read the GPS (GSA)
Sentence setting
(00=OFF, 01=ON)
0198 00/01 Send/read the GPS (VTG)
Sentence setting
(00=OFF, 01=ON)
0199 00/01 Send/read the GPS (GSV)
Sentence setting
(00=OFF, 01=ON)
0200 see p. 20-14 Send/read the GPS Message
0201 see p. 20-13 Send/read the Unproto Address
0202 00/01 Send/read the position data
extension setting
(00=OFF, 01=COURSE/SPEED)
0203 00 to 02 Send/read the GPS-A Time Stamp
setting
(00=OFF, 01=DHM, 02=HMS)
0204 00/01 Send/read the GPS-A altitude
setting
(00=OFF, 01=ON)
0205 00 to 03 Send/read the GPS-A Symbol
( 00=No.1, 01=No.2, 02=No.3,
03=No.4)
0206 see p. 20-13 Send/read the GPS-A Symbol No.1
setting
0207 see p. 20-13 Send/read the GPS-A Symbol No.2
setting
0208 see p. 20-13 Send/read the GPS-A Symbol No.3
setting
0209 see p. 20-13 Send/read the GPS-A Symbol No.4
setting
0210 00 to 42 Send/read the GPS-A SSID
( 00=---, 01=(-0), 02=-1 to 16=-15,
17=-A to 42=-Z)
