Parameter Value
Enable tx_enh_fifo_pfull port On / Off
Enable tx_enh_fifo_empty port On / Off
Enable tx_enh_fifo_pempty port On / Off
RX FIFO mode Interlaken
RX FIFO partially full threshold from 10-29 (no less than pempty_threshold+8)
RX FIFO partially empty threshold 2 to 10
Enable RX FIFO alignment word deletion (Interlaken) On / Off
Enable RX FIFO control word deletion (Interlaken) On / Off
Enable rx_enh_data_valid port On / Off
Enable rx_enh_fifo_full port On / Off
Enable rx_enh_fifo_pfull port On / Off
Enable rx_enh_fifo_empty port On / Off
Enable rx_enh_fifo_pempty port On / Off
Enable rx_enh_fifo_del port (10GBASE-R) Off
Enable rx_enh_fifo_insert port (10GBASE-R) Off
Enable rx_enh_fifo_rd_en port On
Enable rx_enh_fifo_align_val port (Interlaken) On / Off
Enable rx_enh_fifo_align_clr port (Interlaken) On
Table 80. Interlaken Frame Generator Parameters
Parameter Value
Enable Interlaken frame generator On
Frame generator metaframe length 5 to 8192 (Intel recommends a minimum metaframe
length of 128)
Enable frame generator burst control On
Enable tx_enh_frame port On
Enable tx_enh_frame_diag_status port On
Enable tx_enh_frame_burst_en port On
Table 81. Interlaken Frame Synchronizer Parameters
Parameter Value
Enable Interlaken frame synchronizer On
Frame synchronizer metaframe length 5 to 8192 (Intel recommends a minimum metaframe
length of 128)
Enable rx_enh_frame port On
Enable rx_enh_frame_lock port On / Off
Enable rx_enh_frame_diag_status port On / Off
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
109

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
