Intel Arria 10 User Manual

Word
Addr
Bit R/W Name Description
30:28 RW
Override
AN_PAUSE[2:0]
AN_PAUSE value with which to override the current value. The
following bits are defined:
•
Bit-28 = AN_PAUSE [0] = Pause Ability
•
Bit-29 = AN_PAUSE [1] = Asymmetric Direction
•
Bit-30 = AN_PAUSE [2] = Reserved
You must set 0x4C0 bit-5 for this to take effect.
0x4C4 31:0 RW
User base page high
The Auto Negotiation TX state machine uses these bits if the
Auto Negotiation base pages ctrl bit is set. The following bits
are defined:
• [29:5]: Correspond to page bits 45:21 which are the
technology ability.
• [4:0]: Correspond to bits 20:16 which are TX nonce bits.
Bit 49, the PRBS bit, is generated by the Auto Negotiation TX
state machine.
0x4C5 15:0 RW
User Next page low
The Auto Negotiation TX state machine uses these bits if the
AN Next Page control bit is set. The following bits are
defined:
• [15]: next page bit
• [14]: ACK controlled by the state machine
• [13]: Message Page (MP) bit
• [12]: ACK2 bit
• [11]: Toggle bit
For more information, refer to Clause 73.7.7.1 Next Page
encodings of IEEE 802.3ap-2007. Bit 49, the PRBS bit, is
generated by the Auto-Negotiation TX state machine.
0x4C6 31:0 RW
User Next page high
The Auto Negotiation TX state machine uses these bits if the
Auto Negotiation next pages ctrl bit is set. Bits [31:0]
correspond to page bits [47:16]. Bit 49, the PRBS bit, is
generated by the Auto Negotiation TX state machine.
0x4C7 15:0 RO
LP base page low
The AN RX state machine receives these bits from the link
partner. The following bits are defined:
• [15] Next page bit
• [14] ACK which is controlled by the state machine
• [13] RF bit
• [12:10] Pause bits
• [9:5] Echoed Nonce which are set by the state machine
• [4:0] Selector
0x4C8 31:0 RO
LP base page high
The AN RX state machine receives these bits from the link
partner. The following bits are defined:
• [31:30]: Reserved
• [29:5]: Correspond to page bits [45:21] which are the
technology ability
• [4:0]: Correspond to bits [20:16] which are TX Nonce bits
0x4C9 15:0 RO
LP Next page low
The AN RX state machine receives these bits from the link
partner. The following bits are defined:
• [15]: Next page bit
• [14]: ACK which is controlled by the state machine
• [13]: MP bit
• [12] ACK2 bit
• [11] Toggle bit
For more information, refer to Clause 73.7.7.1 Next Page
encodings of IEEE 802.3ap-2007.
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
153
