Intel Arria 10 User Manual

Word
Addr
Bit R/W Name Description
0x4D3 9:0 RW
ber_time_frames
Specifies the number of training frames to examine for bit
errors on the link for each step of the equalization settings.
Used only when ber_time_k_frames is 0.The following values
are defined:
• A value of 2 is about 10
3
bytes
• A value of 20 is about 10
4
bytes
• A value of 200 is about 10
5
bytes
The default value for simulation is 2'b11. The default value for
hardware is 0.
19:10 RW
ber_time_k_frames
Specifies the number of thousands of training frames to
examine for bit errors on the link for each step of the
equalization settings. Set ber_time_m_frames = 0 for time/
bits to match the following values:
• A value of 3 is about 10
7
bits = about 1.3 ms
• A value of 25 is about 10
8
bits = about 11ms
• A value of 250 is about 10
9
bits = about 11 0ms
The default value for simulation is 0. The default value for
hardware is 0xF.
29:20 RW
ber_time_m_frames
Specifies the number of millions of training frames to examine
for bit errors on the link for each step of the equalization
settings. Set ber_time_k_frames = 4'd1000 = 0x43E8 for
time/bits to match the following values:
• A value of 3 is about 10
10
bits = about 1.3 seconds
• A value of 25 is about 10
11
bits = about 11 seconds
• A value of 250 is about 10
12
bits = about 110 seconds
0x4D4 5:0 RO or
RW
LD coefficient
update[5:0]
Reflects the contents of the first 16-bit word of the training
frame sent from the local device control channel. Normally,
the bits in this register are read-only; however, when you
override training by setting the Ovride Coef enable
control bit, these bits become writable. The following fields
are defined:
• [5: 4]: Coefficient (+1) update
— 2'b11: Reserved
— 2'b01: Increment
— 2'b10: Decrement
— 2'b00: Hold
• [3:2]: Coefficient (0) update (same encoding as [5:4])
• [1:0]: Coefficient (-1) update (same encoding as [5:4])
For more information, refer to 10G BASE-KR LD coefficient
update register bits (1.154.5:0) in Clause 45.2.1.80.3 of IEEE
802.3ap-2007.
6 RO or
RW
LD Initialize
Coefficients
When set to 1, requests the link partner coefficients be set to
configure the TX equalizer to its INITIALIZE state. When set
to 0, continues normal operation. For more information, refer
to 10G BASE-KR LD coefficient update register bits (1.154.12)
in Clause 45.2.1.80.3 and Clause 72.6.10.2.3.2 of IEEE
802.3ap-2007.
7 RO or
RW
LD Preset
Coefficients
When set to 1, requests the link partner coefficients be set to
a state where equalization is turned off. When set to 0 the
link operates normally. For more information, refer to 10G
BASE-KR LD coefficient update register bit (1.154.13) in
Clause 45.2.1.80.3 and Clause 72.6.10.2.3.2 of IEEE
802.3ap-2007.
0x4D4 13:8 RO
LD coefficient
status[5:0]
Status report register for the contents of the second, 16-bit
word of the training frame most recently sent from the local
device control channel. The following fields are defined:
continued...
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
157

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
