Parameter Value
warning
Transceiver configuration rules CPRI (Auto)
CPRI (Manual)
PMA configuration rules basic
Transceiver mode TX/RX Duplex
Number of data channels 1-36
Data rate
1228.8 Mbps
2457.6 Mbps
3072 Mbps
4915.2 Mbps
6144 Mbps
8110.08 Mbps
9830.4 Mbps
10137.6 Mbps
(46)
12165.12 Mbps
(46)
Enable datapath and interface reconfiguration Off
Enable simplified data interface On
Table 206. TX PMA Parameters
Parameter Value
TX channel bonding mode Not Bonded / PMA Bonding Only / PMA
and PCS Bonding
TX local clock division factor 1
Number of TX PLL clock inputs per channel 1
Initial TX PLL clock input selection 0
Enable tx_pma_clkout port Off
Enable tx_pma_div_clkout port On
tx_pma_div_clkout division factor 2
Enable tx_pma_elecidle port Off
Enable tx_pma_qpipullup port (QPI) Off
Enable tx_pma_qpipulldn port (QPI) Off
Enable tx_pma_txdetectrx port (QPI) Off
Enable tx_pma_rxfound port (QPI) Off
Enable rx_seriallpbken port Off
(46)
10137.6 Mbps and 12165.12 Mbps are implemented by selecting 10GBase-R or 10GBase-R
1588 under Transceiver configuration rules. The Enhanced PCS is selected when the CPRI data
rate is 10137.6 Mbps and above.
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
286

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
