Intel Arria 10 User Manual

Parameter Range
GT transceiver channel: 1 Gbps
(48)
to 25.8 Gbps
(49)
Enable datapath and interface reconfiguration On / Off
Enable simplified data interface On / Off
Table 212. TX PMA Parameters
Parameter Range
TX channel bonding mode Not bonded, PMA only bonding, PMA and PCS bonding
PCS TX channel bonding master Auto, 0 to n-1, n (where n = the number of data channels)
Actual PCS TX channel bonding master n-1 (where n = the number of data channels)
TX local clock division factor 1, 2, 4, 8
Number of TX PLL clock inputs per channel 1, 2, 3, 4
Initial TX PLL clock input selection 0
Enable tx_pma_clkout port On / Off
Enable tx_pma_div_clkout port On / Off
tx_pma_div_clkout division factor Disabled, 1, 2, 33, 40, 66
Enable tx_pma_elecidle port On / Off
Enable tx_pma_qpipullup port (QPI) On / Off
Enable tx_pma_qpipulldn port (QPI) On / Off
Enable tx_pma_txdetectrx port (QPI) On / Off
Enable tx_pma_rxfound port (QPI) On / Off
Enable rx_serialpbken port On / Off
Table 213. RX PMA Parameters
Parameter Range
Number of CDR reference clocks 1 to 5
Selected CDR reference clock 0 to 4
Selected CDR reference clock frequency For Basic (Enhanced PCS): Depends on the data rate
parameter
For Basic with KR FEC: 50 to 800
PPM detector threshold 100, 300, 500, 1000
CTLE adaptation mode manual
DFE adaptation mode adaptation enabled, manual, disabled
Number of fixed dfe taps 3, 7
Enable rx_pma_clkout port On / Off
continued...
(48)
Applies when operating in reduced power modes. For standard power modes, the Enhanced
PCS minimum data rate is 1600 Mbps.
(49)
The Enhanced PCS must be configured in basic mode to support this data rate range.
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
294

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
