Keysight M8000 Series of BER Test Solutions User Guide 157
User Interface - M8020A Display Views 4
Channels
Displays the channels that are connected to the module. You can select
the channel on which you want to configure channel settings. You can
assign a different color to each channel so that they are easily identified.
For details, refer to Settings Window on page 602.
Using the Zoom Tool
The following figure shows the options provided by the zoom tool.
The zoom tools provide the following functionality:
•The Zoom In button allows you to enlarge the block diagram to
view more details.
•The Zoom Out button allows you to reduce the block diagram.
•The Zoom Slider allows you to zoom in or zoom out the block diagram.
The mouse wheel also provides a quick alternative to the zoom control.
To zoom in and out using the mouse, hold down the [Ctrl] key while
you turn the mouse wheel. Each click, up or down, increases or
decreases the zoom factor by 25%.
•The Fit to View button fits the width of the block diagram so that
the user does not have to scroll the block diagram to the right or to the
left.
