Keysight M8000 Series of BER Test Solutions User Guide 45
Know Your Hardware 2
J-BERT M8051A Generator-Analyzer
The J-BERT M8051A
is an instrument module that can be installed into
the M9505A 5-slot AXIe Chassis. This module occupies two slots and
requires the M8041A module for proper operation.
The M8051A is a two channel Generator and two channel Analyzer for
performing compliance and characterization measurements.
M8051A Features
The main M8051A features are the same as the M8041A features. For
details, refer to J-BERT M8041A Generator-Analyzer-Clock Module on
page 40.
M8051A Module Components
The following figure displays the front panel of the M8051A module with its
various components labeled.
Retaining Screws
Module Insertion/
Extraction Handles
Channel 1 Data
Inputs/Outputs
Channel 2 Data
Inputs/Outputs
Control Inputs/
Output
Front Panel LEDs
Sync In
To Next Page
