54 Keysight M8000 Series of BER Test Solutions User Guide
2 Know Your Hardware
Table 31 Pattern Generator Data Inputs/Outputs
M8062A Front Panel Analyzer Connectors
Table 32 Error Analyzer Data Inputs/Outputs
Table 33 Error Analyzer Clock Inputs/Output
Component Description
Data Out and /Data Out Differential or single-ended, full-rate data output to the device under test. Unused outputs must be
terminated into 50 . (2.4 mm, female).
Data In 1 and Data In 2 Single-ended, half-rate data inputs from the M8041A module (3.5 mm, female).
Component Description
Data In and /Data In Differential or single-ended, full-rate data input from the device under test. Unused input should be terminated
into 50 . (2.4 mm, female). These ports are AC coupled.
Data Out 1 and Data Out 2 Single-ended, half-rate data outputs to the M8041A module (3.5 mm, female).
Component Description
Clk Out Half-rate Error Analyzer clock output, synchronous with analyzer sampling.
Clk In Half-rate, Error Analyzer clock input. Allows external clocking of the Error Analyzer.
