Keysight M8000 Series of BER Test Solutions User Guide 489
Working with Measurements 8
How to Run Output Timing Measurement
To run an Output Timing measurement, perform the following steps:
•Use the Parameters window to select the location or location group for
which the data acquisition has to be performed.
• Set the acquisition and evaluation parameters for Output Timing in the
Parameters Window. For details, refer to Acquisition Parameters on
page 484 and Evaluation Parameters on page 485.
•Click the Start Measurement icon to run the measurement. The
measurement status indicator will indicate Running.
How to Stop Output Timing Measurement
To stop a measurement:
•Click the Stop Measurement icon to stop the measurement.
Analyze Errors Specify options to analyze errors All Errors | Errored
Zeros | Errored
Ones
Vertical Axis Scale Specify the Y axis scale. Linear |
Logarithmic
Display Unit Specify the unit to be displayed. Seconds | UI
Show Measured Points Show/hides the measured points on the
graph.
Show | Hide
Parameters Description Values
