Keysight M8000 Series of BER Test Solutions User Guide 463
Working with Measurements 8
Status Indicator
The status indicator shows the current state of a measurement. There can
be various states of a measurement, depending on the type of
measurement. These may be as follows:
• Not Started: Indicates that the measurement has not yet started.
• Running: Indicates that the measurement is currently running.
• Stop: Indicates that the measurement is stopped.
• Error: Indicates an error while executing the measurement which is
caused due to invalid parameter settings.
• Suspended: Indicates that the measurement is suspended.
• Finished: Indicates that the measurement is completed.
The following figure shows the status indicator while the measurement is
running:
Measurement History Window
The Measurement History window maintains the history of executed
measurement along with their time stamp. This allows you to refer to the
previously run measurements and compare their results.
The Measurement History window is shown in the figure below:
Click the icon to toggle between the enable/disable measurement run
history in the Measurement History window.
