Keysight M8000 Series of BER Test Solutions User Guide 365
Setting up Patterns 7
Exporting a Sequence
The M8070A Sequence Editor allows you to export patterns and use it for
testing and analysis.
To export a pattern:
1Click the Export Sequence icon. This opens the Export Sequence
dialog which allows you to export the sequences from Generator,
Analyzer or both. Additionally, it also allows you to export the patterns
used in the sequences.
2Click OK. A standard Windows Save As dialog will open which allows
you to save the sequence under the defined file name and location.
Creating a Loop
To create a loop (if desired):
•Click the Add Block Before icon to add the blocks before the
selected sequence blocks.
•Click the Add Block After icon to add the blocks after the selected
sequence blocks.
