Keysight M8000 Series of BER Test Solutions User Guide 649
Appendix 11
M8070A Factory Patterns
The M8070A System Software provides a set of example factory supplied
standard patterns. These patterns mimic real data packets and standard
stress patterns.
CEI
DisplayPort
Please note that these patterns are read only and cannot be modified.
However, if you modify these patterns, you will have to save them with
different name at different location.
Pattern Description
CEIstress_bit CEI Stress pattern
CID_bit
QPRBS13-CEI_bit This QPRBS13-CEI pattern is defined by OIF CEI-56G VSR Chapter
16.C.3.1 Draft 13. The quaternary PRBS13 test pattern is a 4-level
pattern created by encoding a repeating PRBS13 pattern using Gray
code and PAM4 encoding. Each cycle of QPRBS13-CEI is 8191 symbols
long. To get correct output symbols the respective generator needs to
have Gray Coding selected.
SSPR_bit
SSPS-16_bit
SSPS-64_bit
Pattern Description
D24.3_b8b10 contains D24.3 symbols; pattern type is
B8B10
DP-TS1_D10.2_b8b10 part of trainings sequence; pattern type
is B8B10
DP-TS2_b8b10 part of trainings sequence; pattern type
is B8B10
