Keysight M8000 Series of BER Test Solutions User Guide 57
Know Your Hardware 2
M8030A Module Setup
The M8030A is a modular test solution which can be tailored to your
specific needs from two channels with one M8041A to up to 10 channels.
The modules must be installed in the M9514A AXIe 14-slot chassis as
described in Table 34 on page -57:
Table 34 M8030A Modules Configuration
Slot Number Module
# 1 M8030A-BU1 AXIe embedded controller.
# 2, 3 & 4 M8041A module
# 5 & 6 M8051A module
# 7 M9521A AXIe system module
# 8 & 9 M8051A module
# 10 & 11 M8051A module
# 12 & 13 M8051A module
# 14 M8192A multi-channel synchronization module
