56 Keysight M8000 Series of BER Test Solutions User Guide
2 Know Your Hardware
4-Channel System
A four-channel system consists of one clock module and one data
modules.
The following figure illustrates a four-channel system.
For more details on how to establish connections between the M8020A
modules, refer to the M8020A/M8030A Installation Guide.
