Keysight M8000 Series of BER Test Solutions User Guide 181
User Interface - M8020A Display Views 4
• High Frequency Jitter profile of Clock and Trigger Out are controlled by
Data Out of channel 1 as shown in the following figure:
• The SSC can be enabled/disabled for all Data Out channels by a single
option as shown in the following figure:
The option to either enable or disable SSC feature is available under
Clock and Trigger column.
The Impairment Setup View also allows you to modify the parameter
values. Depending upon whether the keypad option is enabled or disabled,
the parameter values can be modified in the following ways:
• When the keypad is enabled: In this case when you click on the values
which you want to modify, an on-screen numeric keypad appears as
shown in the following figure:
