7 Setting up Patterns
Table 54 Plain bit coding without using mask or squelch
Table 55 Mask is used
Table 56 Squelch is used
Table 57 Mask and Squelch are used
Bit offset range Bit (range) name Description
0 Data Data bit
Bit offset range Bit (range) name Description
0 Data Data bit
1 Mask Mask (ignored on DataOut)
Bit offset range Bit (range) name Description
0 Data Data bit
1 Squelch Squelch (ignored on DataIn)
Bit offset range Bit (range) name Description
0 Data Data bit
1 Mask Mask (ignored on DataOut)
2 Squelch Squelch (ignored on DataIn)
