Keysight Technologies M8000 Series

Keysight M8000 Series of BER Test Solutions User Guide 583
Utilities 9
M8000.Instrument.Analyzer.DataCenter(groupOrLocationName)
M8000.Instrument.Analyzer.ThresholdCenter(groupOrLocationName)
Functionality Executes a data-center alignment on the addressed locations.
Parameters
groupOrLocationName Addresses the locations that shall be aligned.
The use of .Net regular expression patterns is allowed.
Returns Nothing
Notes • Is blocking until the alignment has finished.
• Not allowed for "DUT_" hooks.
• Not supported for locations defined by the DUT Control
Interface script.
Functionality Executes a threshold-center alignment on the addressed
locations.
Parameters
groupOrLocationName Addresses the locations that shall be aligned.
The use of .Net regular expression patterns is allowed.
Returns Nothing
Notes • Is blocking until the alignment has finished.
• Not allowed for "DUT_" hooks.
• Not supported for locations defined by the DUT Control
Interface script.
