Keysight M8000 Series of BER Test Solutions User Guide 61
Know Your Hardware 2
The M8045A module has the following components.
Table 35 Insertion/Extraction and Retaining
Table 36 Front Panel LEDs
Component Description
Retaining screws The screws on both ends of the module are used to retain the module tightly
inside the M9505A AXIe Chassis slot once you have fully placed it inside the
chassis. To remove the module, you first need to loosen these screws ensuring
that these screws disengage completely.
Module Insertion/Extraction
Handles
The handles on both sides of the module to insert or eject the module from the
slot of the M9505A AXIe Chassis.
Connector Name Active when... Color
Fail power-up fault condition red
Access power-up ready state green
Data Mod In 1/2 signal is detected green
Clk Out 1/2 output is active green
Ctrl Out 1/2 output is active green
Ctrl In 1/2 logic level is detected green
P & N 1/2 output is active green
Clk In signal is detected green
Ref Clk In signal is detected green
Ref Clk Out Outputs a 10 and 100 MHz clock, 1 Vpp single ended
into 50 Ohm
green
Aux In not used n/a
Clk Out output is active green
Trig Out output is active green
