Keysight M8000 Series of BER Test Solutions User Guide 65
Know Your Hardware 2
The M8046A module has the following components.
Table 38 Insertion/Extraction and Retaining
Table 39 Front Panel LEDs
Component Description
Retaining screws The screws on both ends of the module are used to retain the module tightly
inside the M9505A AXIe Chassis slot once you have fully placed it inside the
chassis. To remove the module, you first need to loosen these screws ensuring
that these screws disengage completely.
Module Insertion/Extraction
Handles
The handles on both sides of the module to insert or eject the module from the
slot of the M9505A AXIe Chassis.
Connector Name Active when... Color
Fail power-up fault condition red
Access power-up ready state green
Clk In on when output active and CLK detected green
Ctrl Out on when output active green
Ctrl In logic state is detected green
Data In data received green
