117
THE EXPANDED GUIDE
MENUS
»
CUSTOM SETTING MENU
›
c: Timers/AE Lock
c1 Shutter-release button AE-L
This determines whether you can lock
exposure by half-pressure on the shutter-
release button. By default, this item is Off,
which means that half-pressure locks focus
only (see Focus lock, page 76), and you
can only lock exposure with the
button. Change it to On, and half-pressure
locks both focus and exposure.
c2 Auto off timers
Governs the interval before the relevant
displays turn off when idle. A shorter delay
improves battery life. The displays do not
turn off automatically when the D5300 is
connected to a computer.
The options you can select are Short,
Medium, or Long; these set different
intervals for different camera functions
(see the table below). Short is a good
choice if you want to economize battery
life. You can also set your own Custom
intervals for each of these timers.
Custom Setting c2 Auto off timers
Interval for: Short Normal Long
Playback/menus 20 sec. 1 min. 5 min.
Image review 4 sec. 4 sec. 20 sec.
Live view 5 min. 10 min. 20 min.
Standby timer 4 sec. 8 sec. 1 min.
c3 Self-timer
This menu has two sub-menus governing
the operation of the self-timer.
Self-timer delay determines the interval
between pressing the button and the shot
being taken. The default is 10 sec.,
alternatives are 2, 5, and 20 sec.
As well as taking a single shot, you can
create sequences from one press of the
release button. Number of shots can be set
anywhere from 1 to 9; if you set any value
larger than 1, the interval between
successive shots is approximately 4 sec.
c4 Remote on Duration (ML-L3)
If you’re using the optional ML-L3 remote
control (see page 212), this governs how
long the camera will remain on standby for
a signal from the remote before remote
control mode turns off. Options range
from 1 min (default) to 15 min. This does
not apply in Live View shooting.
Nikon D5300 Ch3 106-137 P2 RY.indd 117Nikon D5300 Ch3 106-137 P2 RY.indd 117 19/02/2014 16:4119/02/2014 16:41
www.ebook777.com

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
