Free ebooks ==> www.ebook777.com
151
THE EXPANDED GUIDE
FLASH
»
USING OPTIONAL SPEEDLIGHTS
Painting with light
You can try this with any flashgun, even
the cheapest, that can be triggered
manually. By firing multiple flashes at the
subject from different directions, you build
up overall coverage of light without losing
the sparkle that directional light gives. It
requires trial and error, but that’s part of
the fun. The basic steps are:
1) Set up so that neither camera nor
subject can move during the exposure.
2) Use Manual mode. Set a long shutter
speed such as 20 or 30 seconds, or even B.
Set a small aperture such as f/16 (this may
need trial and error). Focus on the subject
then turn the focus selector to M so the
camera doesn’t try to refocus.
3) Turn out the lights. It helps to have just
enough background light to see what you
are doing, but no more.
PAINTING WITH LIGHT
This image was created with five bursts of flash:
two from the front left, to illuminate the darkest
areas, and one each from the back left, back
right and front right. 7mm, 15 sec., f/16, ISO 800.
4) Trip the shutter and then fire the flash at
the subject from different directions
(without aiming directly into the lens).
5) Review the result and start again! For
example, if results are too bright, use fewer
flashes, a lower ISO, a smaller aperture,
hold the flash further away, or a
combination. If the flash has a variable
power setting this could be turned down.
Nikon D5300 Ch4 138-157 P2 RY.indd 151Nikon D5300 Ch4 138-157 P2 RY.indd 151 19/02/2014 16:5019/02/2014 16:50
www.ebook777.com

Table of Contents

Other manuals for Nikon D5300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Nikon D5300 and is the answer not in the manual?

Nikon D5300 Specifications

General IconGeneral
Megapixel24.2 MP
Camera typeSLR Camera Body
Sensor typeCMOS
Sensor formatAdvanced Photo System type-C (APS-C)
Image stabilizerNo
Total megapixels24.78 MP
Image sensor size- \
Image formats supportedJPG, RAW
Supported aspect ratios3:2
Maximum image resolution6000 x 4000 pixels
Image sensor size (W x H)23.5 x 15.6 mm
Still image resolution(s)6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom- x
Mounting typeBayonet
Focal length range- mm
Lens mount interfaceNikon F
Minimum aperture number-
FocusTTL
Focus adjustmentAuto/Manual
Auto Focus (AF) lockYes
Auto Focus (AF) points39
Auto focusing (AF) modesContinuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selectionAuto, Manual
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity100, 12800, 25600, Auto
Light exposure modesAperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)25600
ISO sensitivity (min)100
Light exposure correction± 5EV (1/3EV step)
Camera shutter typeElectronic
Fastest camera shutter speed1/4000 s
Slowest camera shutter speed30 s
Flash modesAuto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed1/200 s
Shoe mounting point typeHot shoe
Flash exposure correction-3EV - +1EV (1/3 EV step)
Power source typeBattery
Video resolutions640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate60 fps
Video formats supportedH.264, MOV, MPEG4
Maximum video resolution1920 x 1080 pixels
Analog signal format systemNTSC, PAL
Memory slots1
Internal memory- MB
Compatible memory cardsSD, SDHC, SDXC
Field of view100 %
Display diagonal3.2 \
Display resolution720 x 480 pixels
Display resolution (numeric)1036800 pixels
Magnification0.82 x
Viewfinder typeOptical
USB version2.0
HDMI connector typeMini
Product colorSilver
Scene modesPortrait, Landscape (scenery)
Photo effectsBlack&White, Neutral, Vivid
White balanceAuto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modesRotation, Slideshow, Zoom
Shooting modesAperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playbackHighlights, Movie, Single image, Slide show
Image processorEXPEED 4
Self-timer delay2, 5, 10, 20 s
Camera file systemDCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)-1.7 - 1
On Screen Display (OSD) languagesARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery typeEN-EL14a
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)0 - 85 %
Cables includedUSB
Bundled softwareViewNX 2
Wi-Fi standards802.11b, 802.11g
Weight and Dimensions IconWeight and Dimensions
Depth76 mm
Width125 mm
Height98 mm
Weight480 g
Weight (including battery)530 g
