6
NIKON D5300
1
OVERVIEW
The D5300 is the latest model in Nikon’s advanced “consumer” series,
occupying a middle position in the DX-format camera range, between the
entry-level D3200 and the “enthusiast” or “semi-pro” D7100. The D5XXX
series stands apart from all other Nikon digital SLRs in having an articulating
rear screen, which offers extra flexibility when shooting in Live View and can
be especially helpful when shooting movies.
»
EVOLUTION OF THE NIKON D5300
Nikon has always valued continuity as well
as innovation; for instance, it has retained
its tried and tested F lens-mount (originally
introduced in 1959!). This means it’s
possible to use many classic Nikon lenses
with the latest digital single-lens reflex
cameras (DSLRs) like the D5300, though
care is needed and some camera functions
(e.g. autofocus) may be lost (see Chapter
7, page 184).
Nikon’s first DSLR was the 1.3-megapixel
E2s. It had no rear screen and images could
only be viewed by connecting it to an
external device. A far more practical
introduction was the 2.7-megapixel D1, in
1999. Still the most influential digital
camera ever launched, the D1 was the first
DSLR to approach the flexibility and ease
of handling of 35mm SLRs. Its sensor
adopted the DX format, subsequently used
in every Nikon DSLR until the “full-frame”
(FX) D3 in 2008.
In 2004, Nikon introduced their first
“enthusiast” DSLR, the 6-megapixel D70; its
direct descendants were the D80 (2006)
and then the D90 (2008), but by then the
range had diversified further, with a new
“entry-level” series, beginning with the D40
(2006). This was followed by the D60 (2008)
and then by the D3000, D3100, and D3200.
Meanwhile, the D90 was one of Nikon’s
most significant launches; a range of new
features was overshadowed by one
headline-grabber as it became the first
DSLR capable of shooting video. The D90
remained on sale (and indeed is still listed
today) even as many of its innovations
Nikon D5300 Ch1 001-021 P2 RY.indd 6Nikon D5300 Ch1 001-021 P2 RY.indd 6 19/02/2014 15:3119/02/2014 15:31

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
