163
THE EXPANDED GUIDE
CLOSE-UP
»
MACRO LIGHTING / EQUIPMENT FOR MACRO PHOTOGRAPHY
»
EQUIPMENT FOR MACRO PHOTOGRAPHY
›
Close-up attachment lenses
›
Extension tubes
Product number Attaches to filter thread Recommended for use with
0, 1 52mm Standard lenses
3T, 4T 52mm Short telephoto lenses
5T, 6T 62mm Telephoto lenses
Close-up attachment lenses are simple
magnifying lenses that screw into the filter
thread of the lens. They are light,
convenient, and inexpensive, and fully
compatible with the camera’s exposure
and focusing systems. For best results, it’s
recommended to use them with prime
lenses (see page 187).
Nikon produces six close-up attachment
lenses, see the table below.
Extension tubes are another simple,
relatively inexpensive, way of extending the
close-focusing capabilities of a lens. An
extension tube is essentially a simple tube
fitting between the lens and the camera.
This decreases the minimum focusing
distance and thereby increases the
magnification factor. Again they are light,
compact and easy to carry and attach.
The Nikon system includes four
Extension tubes, PK-11A, PK-12, PK-13,
and PN-11, which extend the lens by 8mm,
14mm, 27.5mm, and 52.5mm respectively.
The PK-11 incorporates a tripod mount.
The basic design of these tubes has not
changed for many years, which means that
many of the camera’s functions are not
available. In particular, there’s no
autofocus. Used on the D5300, you may be
restricted to Manual (M) mode and
exposure determination will be by trial and
error—but that’s what the histogram’s for.
Kenko also produces compatible
extension tubes, which do support matrix
metering, although they still do not
permit autofocus on the D5300. They’re
also far more reasonably priced than
Nikon’s own offerings.
Some recent lenses are not
compatible with accessories such as
extension rings, bellows (see next
page), and teleconverters (see pages
164, 201
). Check the lens manual.
Warning!
Nikon D5300 Ch5 158-167 P2 RY.indd 163Nikon D5300 Ch5 158-167 P2 RY.indd 163 19/02/2014 16:5819/02/2014 16:58
www.ebook777.com

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
