144
NIKON D5300
4
›
Guide Numbers
The Guide Number (GN) is a measure
of the power of a flash. In the past,
photographers used GNs constantly to
calculate flash exposures and working
range. With modern flash metering, like
Nikon’s i-TTL system (see below), such
computations are rarely needed. However,
the GN does help us to compare different
flashguns. For instance, the GN for the
built-in flash is 12 (meters, ISO 100); for the
Nikon SB-910 it is 34, indicating almost
three times the power. This allows shooting
at three times the distance, at a lower ISO,
or with a smaller aperture.
Tip
GNs are specifi ed in feet and/or
meters and usually for an ISO rating
of 100. When comparing diff erent
units, be sure that both GNs are stated
in the same terms.
Flash, as the name implies, is virtually
instantaneous, lasting just a few
milliseconds. If the flash is to cover the
whole image frame it must be fired when
the shutter is fully open, but at faster
shutter speeds DSLRs like the D5300 do not
FLASH MODE SETTING IN THE ACTIVE
INFORMATION DISPLAY
Standard flash mode
(front-curtain sync)
This is the default flash mode in most
exposure modes. However, the flash mode
item in the Active Information Display
labels it “Fill-flash” when using P, S, A, and
M exposure modes and “Auto flash” in
other modes.
In standard flash operation, the flash
fires as soon as the shutter is fully open, i.e.
as soon as possible after the shutter-release
button is pressed. This gives a fast response
›
Flash synchronization
and flash modes
in fact expose the whole frame at once. In
the case of the D5300, the fastest shutter
speed which can be used with flash is
1/200 sec. This is therefore known as the
sync (for synchronization) speed.
Flash modes are distinguished by how
they regulate synchronization and shutter
speed. Choose a flash mode by pressing
and rotating the Command Dial, or using
the Active Information Display.
Nikon D5300 Ch4 138-157 P2 RY.indd 144Nikon D5300 Ch4 138-157 P2 RY.indd 144 19/02/2014 16:4919/02/2014 16:49

Nikon D5300 Specifications

General

Megapixel	24.2 MP
Camera type	SLR Camera Body
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	No
Total megapixels	24.78 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	3:2
Maximum image resolution	6000 x 4000 pixels
Image sensor size (W x H)	23.5 x 15.6 mm
Still image resolution(s)	6000 x 4000, \\r 4496 x 3000, \\r 2992 x 2000
Optical zoom	- x
Mounting type	Bayonet
Focal length range	- mm
Lens mount interface	Nikon F
Minimum aperture number	-
Focus	TTL
Focus adjustment	Auto/Manual
Auto Focus (AF) lock	Yes
Auto Focus (AF) points	39
Auto focusing (AF) modes	Continuous Auto Focus, Contrast Detection Auto Focus, Multi Point Auto Focus, Servo Auto Focus, Single Auto Focus, Tracking Auto Focus
Auto Focus (AF) points selection	Auto, Manual
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 12800, 25600, Auto
Light exposure modes	Aperture priority AE, Auto, Manual, Shutter priority AE
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 5EV (1/3EV step)
Camera shutter type	Electronic
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash sync-speed	1/200 s
Shoe mounting point type	Hot shoe
Flash exposure correction	-3EV - +1EV (1/3 EV step)
Power source type	Battery
Video resolutions	640 x 424, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	60 fps
Video formats supported	H.264, MOV, MPEG4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Memory slots	1
Internal memory	- MB
Compatible memory cards	SD, SDHC, SDXC
Field of view	100 %
Display diagonal	3.2 \
Display resolution	720 x 480 pixels
Display resolution (numeric)	1036800 pixels
Magnification	0.82 x
Viewfinder type	Optical
USB version	2.0
HDMI connector type	Mini
Product color	Silver
Scene modes	Portrait, Landscape (scenery)
Photo effects	Black&White, Neutral, Vivid
White balance	Auto, Cloudy, Flash, Fluorescent, Incandescent, Manual, Shade, Sunny
Playback modes	Rotation, Slideshow, Zoom
Shooting modes	Aperture priority, Auto, Lens priority, Manual, Movie, Program, Scene, Shutter priority
Camera playback	Highlights, Movie, Single image, Slide show
Image processor	EXPEED 4
Self-timer delay	2, 5, 10, 20 s
Camera file system	DCF 2.0, DPOF 1.1, Exif 2.3, RAW
Diopter adjustment (D-D)	-1.7 - 1
On Screen Display (OSD) languages	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, FIN, FRE, GRE, HUN, ITA, JPN, KOR, NOR, POL, POR, RUM, RUS, SWE, THA, TUR, UKR
Battery type	EN-EL14a
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	0 - 85 %
Cables included	USB
Bundled software	ViewNX 2
Wi-Fi standards	802.11b, 802.11g

Weight and Dimensions

Depth	76 mm
Width	125 mm
Height	98 mm
Weight	480 g
Weight (including battery)	530 g
