Adjusting the Images That Were Taken
104
FQ2-S/CH User’s Manual
Applying the Results of Position Compensation
You can apply the results of position compensation either to the Camera image or to the previous image from
before position compensation was applied.
If you apply the results of position compensation to the Camera image, only the position information from
position compensation is applied to the image to be measured.
Using Filter Items for Processing with Position Compensation Items: p. 106
• Setting the Image for Position Compensation
You can select the image to which to apply the results of position compensation processing.
You can set the image for position compensation for each position compensation item.
[Image] − [Image adjustment] − (Position compensation item name) − [Modify]
1 Touch [Details] − [Scroll parameter]
2 Set the source image to [Camera] or [Prev.].
Parameter Setting Description
Source image
Camera
(Camera Image)
The results of processing the position compensation item is applied
to the image that is taken by the Camera.
This setting is used when filter items or other position compensation
items have been used specifically for the position compensation
item.
Using Filter Items for Processing with Position Compensation Items:
p. 106
Prev.
(previous image)
(default)
This setting is used when the processing results of the current
position item are to be applied to the image that results from previous
filter items or other position compensation items.
To Next Page
