Omron FQ2-S/CH Series User Manual

Adjusting the Images That Were Taken
116
FQ2-S/CH User’s Manual
• Source Image
You can select the image to which to apply the results of position compensation processing.
Applying the Results of Position Compensation: p.104
• Interpolation
You can select the precision of position compensation.
If you select [Bilinear], the precision of position compensation will increase.
[Image] − [Image adjustment] − [2Edge position comp.] − [Modify] − [Details] − [Interpolation]
The settings are the same as those for the Shape Search Position Compensation item.
Interpolation: p. 108
• Measurement Data That Can Be Used for External Outputs and Calculations
The following values can be used as measurement data and output to external devices via Ethernet or used in
calculations.
Expression
text string
Data name Description Data range
JG Judgement This is the judgement result.
-2: No judgement (not measured)
0: Judgement is OK
-1: Judgement is NG
-15: Out of range error
DX Scroll X This is the amount of position
compensation for the X coordinate.
-99,999.9999 to 99,999.9999
DY Scroll Y This is the amount of position
compensation for the Y coordinate.
-99,999.9999 to 99,999.9999
X0 Edge 0 position X This is the X coordinate of the
measured edge 0 position.
-99,999.9999 to 99,999.9999
Y0 Edge 0 position Y This is the Y coordinate of the
measured edge 0 position.
-99,999.9999 to 99,999.9999
X1 Edge 1 position X This is the X coordinate of the
measured edge 1 position.
-99,999.9999 to 99,999.9999
Y1 Edge 1 position Y This is the Y coordinate of the
measured edge 1 position.
-99,999.9999 to 99,999.9999
SX0 Edge0 ref. position X
(edge 0 reference position X)
This is the X coordinate of the edge
0 position when it was registered.
-99,999.9999 to 99,999.9999
SY0 Edge0 ref. position Y
(edge 0 reference position Y)
This is the Y coordinate of the edge
0 position when it was registered.
-99,999.9999 to 99,999.9999
SX1 Edge1 ref. position X
(edge 1 reference position X)
This is the X coordinate of the edge
1 position when it was registered.
-99,999.9999 to 99,999.9999
SY1 Edge1 ref. position Y
(edge 1 reference position Y)
This is the Y coordinate of the edge
1 position when it was registered.
-99,999.9999 to 99,999.9999
