Omron FQ2-S/CH Series User Manual

Logging Measurement Data and Image Data
FQ2-S/CH User’s Manual
399
7
Convenient Functions
Changing the Format for Saving Measurement Data
The output CSV file format can be changed according to the external device.
(Setup Mode or Run Mode) − [TF settings] − [File format] − [Logging data file]
1 Press [Output format].
2 Change the required items in the CSV format.
3 Press [Back].
Enabling File Logging
You must enable file logging before you can execute it.
(Setup Mode) − [TF settings] − [Logging setting]
1 Press [ON].
Starting and Stopping Logging
After logging is started (i.e., set to ON), the specified image data and measurement data will be saved in the
SD card or computer hard disk each time measurements are performed.
(Run Mode)
1 Press [Logging].
2 Press [Image logging] or [Data logging].
3 Press [ON] to start logging.
Press [OFF] to stop logging.
4 Press [Back].
Item Symbol
Field separator None, comma (Default), tabs, space, colon, semicolon, CR, or CR+LF
Decimal symbol None, point (Default), or comma
Record separator None, comma, tabs, space, colon, semicolon, CR, or CR+LF (Default)
To save logged data, you must first select either [All] (all data is saved) or [Only NG] (only NG data is saved) in the
logging parameters.
Setting Logging Conditions: p. 395
Note
