Omron FQ2-S/CH Series

Menu Tables
FQ2-S/CH User’s Manual
455
Appendices
9
Inspection
Details
(OCR*
4
)
Date Parameters
Date Setting
Zero Sup-
press
Select the method for Zero Suppress. 0 (Default)
Blank
p. 159
Date Calc.
Order
Select the calculate method when the
Period Setting is set,
Month → Day (Default)
Day → Month
Month end
adjust
Select the adjust method when not
exist day is calculated.
Last day of current month (Default)
First day of next month
Gap day of next month
Common Setting
Auto
Update
Set the Update method.
Don’t Update
Fist Update
Always Update (Default)
Scene
Back
Margin
Set the Time Margin that is before the
current time.
0 to 99 (Default: 0)
Ahead
Margin
Set the Time Margin that is after the
current time. 0 to 99 (Default: 0)
Code data
Output parameter
File name Displays the file name of code data. Scene
Reflect
Specifies whether to reflect the judg-
ment results of an inspection item in
the overall judgment.
Yes (Default)
No Scene p. 146
Error string Sets the character string that is output
for read errors.
20 alphanumeric characters
(Default: NG)
Scene p. 158
(Bar code*
3
)
Meas. Parameter Same as [Teach] − [Meas. Parameter]
under [Modify] or [Inspection].
Scene p. 186
Output parameter
Reflect Specifies whether to reflect the judg-
ment results of an inspection item in
the overall judgment.
Yes (Default)
No
Scene p. 185
Error string Sets the character string that is output
for read errors.
20 alphanumeric characters
(Default: NG)
Scene p. 187
(2D-code*
3
)
Meas. Parameter Same as [Teach] − [Meas. Parameter]
under [Modify] or [Inspection].
Scene p. 196
Output parameter
Reflect
Specifies whether to reflect the judg-
ment results of an inspection item in
the overall judgment.
Yes (Default)
No
Scene p. 196
Error string Sets the character string that is output
for read errors.
20 alphanumeric characters
(Default: NG)
Scene p. 198
(2D-code (DPM)*
3
)
Meas. Parameter Same as [Teach] − [Meas. Parameter] under [Modify] or [Inspection]. Scene p. 210
Output parameter
Reflect
Specifies whether to reflect the judg-
ment results of an inspection item in
the overall judgment.
Yes (Default)
No Scene ---
Error string Sets the character string that is output
for read errors.
20 alphanumeric characters
(Default: NG)
Scene p. 212
Menu command Description Setting range Data
