Omron FQ2-S/CH Series User Manual

External Reference Parameters
FQ2-S/CH User’s Manual
517
Appendices
9
170 Output
parame-
ter
String output ON/OFF
(memory link)
Set / Get 0: OFF
1: ON
0 --- ---
171 NG error code output
(memory link)
Set / Get 0: OFF
1: ON
1 --- ---
172 Partial output ON/OFF
(memory link)
Set / Get 0: OFF
1: ON
0 --- ---
173 Output end digit (mem-
ory link)
Set / Get 1 to 1024 1024 --- ---
174 Output beginning digit
(memory link)
Set / Get 1 to 1024 1 --- ---
180 Mea-
sure-
ment
condition
GS conversion Set / Get 0: OFF
1: ON
0
--- ---
181 Replacement charac-
ter string
Set / Get Maximum 16 characters None --- ---
186 Print quality Set / Get 0: OFF
1: ON
0 --- ---
190 Grid correction
(MicroQR Code)
Set / Get 0: OFF
1: ON
0 --- ---
202+3N
(N=0 to
31)
*1
Verifica-
tion con-
dition
Master data N Set / Get 32 characters max. None --- ---
300+N
(N=0 to
31)
Reference unit number
N
Set / Get 0 to 31 0 --- ---
410 Logging
condi-
tions
Data logging switch for
unit
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
411 Data logging switch for
judgement
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
412 Data logging switch for
number of characters
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
440 Data logging switch
(overall quality)
Set / Get 0: Data logging OFF
1: Data logging ON
1 --- ---
441 Data logging switch
(decode)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
442 Data logging switch
(cell contrast)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
443 Data logging switch
(cell modulation)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
444 Data logging switch
(fixed pattern damage)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
445 Data logging switch
(axial nonuniformity)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
446 Data logging switch
(grid nonuniformity)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
447 Data logging switch
(unused error correc-
tion)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
448 Data logging switch
(print scale)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
449 Data logging switch
(print scale X)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
450 Data logging switch
(print scale Y)
Set / Get 0: Data logging OFF
1: Data logging ON
0 --- ---
External
refer-
ence
number
Category Data name Set / Get Data range Default Expres-
sion text
string
Logged data/
Judgement
parameter
